DO0134
For Charter From Direct Owners
Reference | DO0134 |
Type | Multicat |
Class | BV |
Build year / place | 2003 / NETHERLANDS |
Length (m) | 26 |
Breadth (m) / Depth (m) | 11.5 / |
NT (tons) / GT (tons) | / |
Engine(s) power (BHP) | 2300 |
Engine(s) | 3 x Cummins KTA19-M3 |
Location | USG |
Price | POA |
Interested in this vessel?
Please, feel free to contact us at any time.
We remain at your entire disposal.
Detailed Information
General
Built Year & Place | 2003 / NETHERLANDS |
Hull Material | Steel |
Flag | UNITED KINGDOM |
Class Society and Notation | BV Tug Unrest. Nav. |
Next DD | |
Next SS | |
Next Annual Survey |
Principle Dimensions
Length Overall (m) | 26 |
Length Between Prep. (m) | |
Breadth (m) | 11.5 |
Depth (m) | |
Draft (m) | 2.5 |
NT (tons) | |
GT (tons) | |
DWT (tons) |
Machinery & Propulsion
Total Power Output (BHP) | 2300 |
Main Engine(s) | 3 x Cummins KTA19-M3 |
Main Propulsion System | Triple screw |
Auxiliary engine(s) | |
Propellers | 3 |
Speed Maximum (knots) | |
Speed Cruising (knots) | 10.5 |
Cargo & Tank Capacities
Deck Cargo (tons) | |
Deck Area (m2) | |
Deck Load (tons/m2) | |
Fuel Tanks Capacity (m3) | 140 |
Fresh Water Tanks Capacity (m3) | 60 |
Ballast Tanks Capacity (m3) |
Additional Information
OTHER DETAILS
Draft min workin 1.9 m
M/E: driving 1550 mm diameter fixed pitch propellers in nozzles through Reintjes reduction gearboxes.
Bollard pull: 29.5 tonnes
NAVIGATION AIDS
GPS and Magnetic compasses, 2 x radars, echosounder, DGPS, Navtex, autopilot, MF/HF radio, 2 x DSCVHF radios, electronic chartplotter, email, satellite phone, searchlights, loudhailers and intercoms.
EQUIPMENT
70t/m and I 50t/m Effer hydraulic long reach cranes, capacity 13.5 tonnes at 11.6 m reach and 6.2 tonnes at 11.6 m with winch repectively
Towing winch 500 m x 36 mmm diameter wire, 30 tonnes pull,
Tugger winch, 100 x 18 mm diameter wire, 8 tonne pull.
Anchor handling winch 100 m x 50 mm diameter wire, 80 tonnes pull,
I50 tonne bow roller,
2 towing hooks – 15 and 30 tonnes,
survey facilities protected by u.p.s system,
1000 mm moonpool,
hydraulic 360 degree bowthruster, 325 bhp.
Capstan, towing and anchor handling equipment.
ACCOMMODATION
Comfortable air conditioned accommodation for 5 people in 3 cabins
