COB0133
For Sale From Owners Representatives
| Reference | COB0133 |
| Type | Offshore - Supply Support Vessel |
| Class | CCS CSA Cable Layer |
| Build year / place | 2025 / CHINA |
| Length (m) | 120 |
| Breadth (m) / Depth (m) | 40 / 9 |
| NT (tons) / GT (tons) | 3613 / 12045 |
| Engine(s) power (BHP) | 2355 |
| Engine(s) | 6 x Yu Chai YC8CAX2400L |
| Location | CHINA |
| Price | 60,000,000 USD |
Interested in this vessel?
Please, feel free to contact us at any time.
We remain at your entire disposal.
Detailed Information
General
| Built Year & Place | 2025 / CHINA |
| Hull Material | Steel |
| Flag | CHINA |
| Class Society and Notation | CCS CSA Cable Layer DP-2;G-ECO(BWM(T)) |
| Next DD | |
| Next SS | |
| Next Annual Survey |
Principle Dimensions
| Length Overall (m) | 120 |
| Length Between Prep. (m) | 115.18 |
| Breadth (m) | 40 |
| Depth (m) | 9 |
| Draft (m) | 6.2 |
| NT (tons) | 3613 |
| GT (tons) | 12045 |
| DWT (tons) | 15316 |
Machinery & Propulsion
| Total Power Output (BHP) | 2355 |
| Main Engine(s) | 6 x Yu Chai YC8CAX2400L |
| Main Propulsion System | Azimuth Thrusters |
| Auxiliary engine(s) | 1 X 240 KW , Yu Chai YC6MK330L-C21 |
| Propellers | |
| Speed Maximum (knots) | |
| Speed Cruising (knots) | 12 |
Cargo & Tank Capacities
| Deck Cargo (tons) | |
| Deck Area (m2) | |
| Deck Load (tons/m2) | |
| Fuel Tanks Capacity (m3) | |
| Fresh Water Tanks Capacity (m3) | |
| Ballast Tanks Capacity (m3) |
Additional Information
Cable Layer
New building – To be delivered in JUL 2025.
MARINE DIESEL OIL : 1500 m3
Navigation Area Unrestricted Area
CLASS NOTATION ★CSA Cable Layer;SPS; PSPC(B); In-Water Survey ★CSM BRC;Electrical Propulsion System; DP-2;G-ECO(BWM(T))
Clear Deck Space TBA m2
Deck Loading 10 – 15 t/m2
DYNAMIC POSITIONING
DP System Praxis Automation Technology BV
DP Class 2
Referenc e System #1 02 x DGPS
Reference System #2 Laser Reference System TBA
CAPACITY (APPROXIMATE)
MDO 727 m3
MGO 727 m3
Fresh Water 567 m3
OPERATING CAPABILITIES
Significant Wave Height ≤ 2.5m
Current ≤ 3 kts
Wind Speed ≤ 17.8 m/s
Endurance 3,000 nm
CABLE LAY CAPABILITIES
Cable Capacity 12,000 ton
Cable OD 38 m
Cable Lay Speed ≤ 15 m/min
Able to deploy subsea soft pipes not exceeding 600mm in diameter.
MACHINERY
Main Generator 06 Units
Engine Maker Yu Chai Machinery Co. Ltd
Model YC8CAX2400L-C22
Rated Power 1756 kW
Fuel Type MDO / MGO
Fuel Consumption 195 g/kW.h
Generator maker Kang Fu Technology
Model SB-HW4-1600-6P
Rated Power 1600 kW
Power Source 690V / 50 Hz / 3P
Rated Speed 1000 rpm
Emergency Genset 01 Unit
Engine Maker Yu Chai Machinery Co. Ltd
Model YC6MK330L-C21
Rated Power 240 kW
Fuel Type MDO
Fuel Consumption 189 g/kW.h
Generator maker Kang Fu Technology
Model SB-HW4.D-200
Rated Power 200 kW
Power Source 400V / 50 Hz / 3P
Rated Speed 1500 rpm
PROPULSION
Azimuth Thrusters 02 x 2240 kW FPP
Bow Thrusters 02 x 2200 kW FPP Bi-directional
CRANE (API-2C)
Main Crane Maker Kai Yuan Heavy Industry Xing Hua Co. Ltd
Working Radius Min 6 m; Max 35m
Lifting Speed 15 m/min
Crane Capacity 45 T @ 28 m; 36 T @ 35 m
Aux Crane Maker Kai Yuan Heavy Industry Xing Hua Co. Ltd
Working Radius Min 5.7 m; Max 30m
Lifting Speed 15m/min
Crane Capacity 8T @ 20 m; 5T @ 30 m
NAVIGATION & COMMUNICATIONS
X Band Radar 01
S Band Radar 01
Magnetic Compass 01
Gyro Compass (w/repeaters) 03
AIS 01
Echo Sounder 01
Doppler Speed Log 01
ECDIS 01
Anemometers 02
VDR 01
Weather Facsimile 01
BNWAS 01
GMDSS A1+A2+A3
NAVTEX 01
Portable HH VHF 03
FACILITIES
Client Office 02
Meeting Room 01
Recreation Room 01
Fitness Room 01
Prayer Room 01
Hospital 01
ACCOMMODATION
Total Berths 86 pax
1 man cabins 16
2 man cabins 35
LIFE SAVING EQUIPEMENT
Life Rafts 2 x 25 pax on each side
Life Boat 2 x 50 pax on each side
BALLAST WATER TREATMENT PLANT
600 m3/hr capacity in compliance with D-2 standards of BWM Convention 2004
